Thread Standard | G | BSPT | Whit Worth | Cutting Direction (HAND) | Right Hand |
Threads per Inch (TPI) | 28-19 | 24-20 | Application | External Threading |
Corner Radius (RE) | 0.004″ | Applicable Material | Stainless Steel | Super-Alloys / Titanium |
Insert Thickness (S) | 1/8″ | Number of Teeth | 3 |
Inscribed Circle Diameter (IC) | 3/8″ | Profile Included Angle (PNA) | 55 Degrees |
Insert Size | 32 | Series/List # | KTTX |
Grade | PR1115 | Mounting Style | Screw |
Coating | TiAlN | Measurement Type | Inch |
Cutting Edge Material | Carbide | Insert Style | TTX |
Cutting Position | External | Coating Process | PVD |
