Thread Standard | G | BSPT | Whit Worth | Cutting Direction (HAND) | Right Hand |
Threads per Inch (TPI) | 28-11 | 24-7 | 24-8 | Application | External Threading | Internal Threading |
Corner Radius (RE) | 0.004″ | Applicable Material | Stainless Steel | Super-Alloys / Titanium |
Insert Thickness (S) | 3/16″ | Number of Teeth | 3 |
Inscribed Circle Diameter (IC) | 1/2″ | Profile Included Angle (PNA) | 55 Degrees |
Insert Size | 43 | Series/List # | KTT |
Grade | PR930 | Mounting Style | Screw |
Coating | TiCN | Measurement Type | Inch |
Cutting Edge Material | Carbide | Insert Style | TT |
Cutting Position | Internal & External | Coating Process | PVD |
