Cutting Diameter (DC/DCX) | 3.512″ | Coolant Supply Property (CSP) | External |
Cutting Diameter (DC) | 3″ | Body Material | Steel |
Cutting Diameter Maximum (DCX) | 3.512″ | Cutting Direction (HAND) | Right Hand |
Cutting Item Count (CICT) | 8 | Application | Facing | Chamfering |
Depth of Cut Maximum (APMX) | 0.2362″ | Measurement Type | Inch |
Connection Diameter Machine Side (DCONMS) | 1″ | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
Overall Length (OAL) | 1.9685″ | Tool Type | Face Mill |
Master Insert Identification (MIID) | PNMU1205… | PNEU1205… | Series/List # | MFPN |
