Cutting Diameter (DC/DCX) | 63 mm | Ramping Angle Maximum (RMPX) | 2 Degrees |
Cutting Diameter (DC) | 63 mm | Coolant Supply Property (CSP) | Coolant Thru |
Cutting Diameter Maximum (DCX) | 63 mm | Body Material | Steel |
Cutting Item Count (CICT) | 5 | Cutting Direction (HAND) | Right Hand |
Depth of Cut Maximum (APMX) | 1.5 mm | Application | Facing | Helical Milling | Plunging | Ramping | Shouldering | Slotting |
Connection Diameter Machine Side (DCONMS) | 22 mm | Measurement Type | Metric |
Overall Length (OAL) | 50 mm | Tool Cutting Edge Angle (KAPR) | 10 Degrees |
Hub Diameter (DHUB) | 60 mm | Series/List # | MFHR |
Master Insert Identification (MIID) | SOMT10 |
