Cutting Diameter (DC/DCX) | 80 mm | Master Insert Identification (MIID) | APMT2506 |
Cutting Diameter (DC) | 80 mm | Coolant Supply Property (CSP) | External |
Cutting Diameter Maximum (DCX) | 80 mm | Body Material | Steel |
Cutting Item Count (CICT) | 16 | Cutting Direction (HAND) | Right Hand |
Depth of Cut Maximum (APMX) | 90 mm | Application | Facing | Heavy Milling | Shouldering | Slotting |
Connection Diameter Machine Side (DCONMS) | 27 mm | Measurement Type | Metric |
Overall Length (OAL) | 115 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
Hub Diameter (DHUB) | 55 mm | Series/List # | MSR |
